Description
The XAC-A8713 Pendant Control Station is designed for industrial hoists, cranes, and machine control systems, offering both safety and precision.
It features 6 mechanically interlocked push buttons and 1 trigger-action latching emergency stop (ZA2-BS44) with a Ø40mm mushroom head operator, ensuring safe operation even in demanding industrial environments.
The enclosure is made from double-insulated yellow polypropylene, providing high visibility, impact resistance, and protection against dust and water with an IP65 rating.
This pendant control station conforms to IEC947-5-1, EN60947-5-1, and VDE0660 standards, ensuring international safety compliance.
Built for 1 million mechanical operations, it guarantees long-term durability and consistent performance.
Ideal for OEM motor control solutions, automation systems, and lifting equipment manufacturers, the XAC-A8713 provides a compact, ergonomic, and dependable control solution for single-speed operation.
- Product Features
6 mechanically interlocked buttons prevent dual operations
Ø40mm ZA2-BS44 emergency stop with trigger latching
Durable double-insulated yellow polypropylene housing
IP65 waterproof and dustproof protection
- Long mechanical lifespan of 1 million operations
Technical Specifications
| Specification | Details |
|---|---|
| Standards | IEC947-5-1, EN60947-5-1, IEC337-1, NFC63-146, VDE0660 |
| Approvals | NEMKO, UL Listed A600-Q600, CSA A600-Q600 |
| Shock Resistance | 100g (IEC68-2-27) |
| Electric Shock Protection | Class II (IEC536, NFC 20-030) |
| Protection Degree | IP65 (IEC 539), IP657 (NF C20-010) |
| Mechanical Durability | 1 million cycles |
| Enclosure | Double-insulated polypropylene, yellow |
| Thermal Current (Ith) | 10A |
| Rated Insulation Voltage (Ui) | 600V (pollution degree 3) |
| Impulse Withstand Voltage (Uimp) | 6kV (IEC947-1) |
| Operation Type | N/C positive opening operation |
| Terminal Capacity | 0.5–2.5mm² screw and cable clamp terminals |
| Emergency Stop | Ø40mm ZA2-BS44, trigger latching, positive opening |
Applications
The XAC-A8713 control pendant is ideal for a wide range of industrial and automation uses.
Common applications include:
Crane and hoist control systems
Conveyor, packaging, and assembly line control
Industrial automation and OEM control panels
Machinery requiring single-speed motor operation
