Pendant Station XAC-A671 Manufacturer
Durable XAC-A671 pendant control station for single-speed motor operation, featuring 8 mechanically interlocked buttons and IP65 protection for industrial use.
- Conforming to standards: IEC947-5-1,EN60947-5-1,IEC337-1,NFC63-146,VDE0660-200
- Enclosure A: Double insulated polypropylene, coloured yellow througout
- Thermal current(Ith) V: 10
The XAC-A671 Pendant Control Station Series is designed for reliable control of single-speed motors in industrial environments. Built with 8 mechanically interlocked buttons, it ensures safe and precise operation, preventing accidental commands between pairs. The housing is crafted from double-insulated yellow polypropylene, offering superior visibility and durability in demanding work conditions.
Conforming to IEC947-5-1, EN60947-5-1, and other international standards, this control pendant delivers exceptional performance and long-term dependability. Its IP65-rated enclosure provides effective protection against dust and moisture, making it ideal for factories, workshops, and outdoor applications. With mechanical durability up to 1 million operations, it’s built to last even in continuous-use environments.
Engineered for safety and efficiency, the XAC-A671 pendant control station simplifies motor control operations while maintaining strict electrical safety compliance. Available for OEM/ODM customization to meet specific control system requirements.
Electrical schematic
Meta Description
Source XAC-A671 Pendant Station from a trusted supplier, manufacturer, and OEM/ODM factory. Wholesale price support for distributors and contractors.
Product Details
The XAC-A671 Pendant Station is a durable industrial control unit designed for single-speed motor operation in cranes, hoists, lifting systems, and material handling equipment. Built with 8 mechanically interlocked push buttons, it helps prevent conflicting commands and improves operational safety and precision in demanding working environments. This model is widely used by industrial users, commercial users, electrical contractors, and distributors in factory automation, workshop lifting equipment, and machine control systems. For B2B buyers, it is a practical choice for suppliers, manufacturers, wholesalers, distributors, and factories looking for a reliable control solution with custom and OEM/ODM sourcing potential. The yellow double-insulated polypropylene enclosure, IP65 protection, and strong mechanical durability make the XAC-A671 Pendant Station suitable for long-term use while maintaining value at a competitive wholesale price.
Product Parameters
- Model: XAC-A671
- Control Configuration: 8 mechanically interlocked push buttons for single-speed motor control
- Protection & Material: IP65 protection, double-insulated yellow polypropylene enclosure, IK08 impact rating
- Electrical & Durability: 10A thermal current, 600V rated insulation voltage, mechanical durability up to 1,000,000 cycles
Product Features
Designed for single-speed motor control
8 interlocked pushbuttons prevent simultaneous activation
IP65 waterproof protection for harsh environments
Double-insulated polypropylene yellow enclosure Long mechanical life up to 1 million cycles
Technical Specifications
| Specification | Details |
|---|---|
| Standards | IEC947-5-1, EN60947-5-1, IEC337-1, NFC63-146, VDE0660 |
| Approvals | NEMKO, UL Listed A600-Q600, CSA A600-Q600 |
| Shock Resistance | 100g (IEC68-2-27) |
| Electric Shock Protection | Class II (IEC536, NFC 20-030) |
| Degree of Protection | IP65 (IEC 539), IP657 (NF C20-010) |
| Mechanical Durability | 1 million operations |
| Enclosure | Double-insulated polypropylene, yellow |
| Thermal Current (Ith) | 10A |
| Rated Insulation Voltage (Ui) | 600V (pollution degree 3) |
| Impulse Withstand Voltage (Uimp) | 6kV (IEC947-1) |
| Operation | N/C positive opening operation |
| Terminal Capacity | 0.5–2.5mm² screw and cable clamp terminals |
Operation effect
Applications
The XAC-A671 control pendant is ideal for industrial automation and lifting systems.
Typical applications include:
Control of hoists, cranes, and single-speed motors
Machine tools, conveyor systems, and packaging lines
Industrial OEM automation and control panels
FAQ
- 1. What is the XAC-A671 Pendant Station used for?
The XAC-A671 Pendant Station is used for single-speed motor control in cranes, hoists, material handling systems, and industrial machinery that require safe and accurate manual operation. - 2. How many buttons does the XAC-A671 Pendant Station have?
The Wilmall product listing describes the XAC-A671 Pendant Station as having 8 mechanically interlocked buttons, designed to reduce the risk of conflicting control commands during operation. - 3. Is the XAC-A671 suitable for wholesale, distributor, or factory purchasing?
Yes. The XAC-A671 is well suited for suppliers, manufacturers, wholesalers, distributors, and factories seeking a durable pendant control product for industrial supply, project procurement, and replacement demand. This B2B positioning is based on its published industrial-use design and protection features. - 4. Can this Pendant Station support custom or OEM/ODM requirements?
Yes. The Wilmall page explicitly positions the XAC-A671 with OEM/ODM language, making it a suitable option for custom sourcing discussions and private-label or project-based procurement needs. - 5. Why is the XAC-A671 a good choice for industrial environments?
The XAC-A671 Pendant Station is built with a double-insulated polypropylene enclosure, IP65 protection, and strong mechanical durability, making it suitable for dusty, wet, and high-use industrial environments.
